Application Performance Center - Service Status Board

Show Affected Only

Affected:

6/6 Trans Type

1/2 Return Code

1/1 Server IP

1/1 Client IP

Trans Type

Name	Transaction Volume	Response Rate	Impact
CardAuth	3.2K → 3.0K(-187)	99.8% → 99.6%(↓ -0.2pp)	18.2%
CardVerify	2.8K → 2.7K(-94)	99.7% → 99.5%(↓ -0.2pp)	15.4%
CardBalance	2.1K → 2.0K(-63)	100.0% → 99.8%(↓ -0.2pp)	12.7%
CardPayment	1.9K → 2.0K(+41)	99.9% → 99.7%(↓ -0.2pp)	11.8%
CardRefund	1.4K → 1.3K(-52)	99.6% → 99.5%(↓ -0.1pp)	9.3%
CardInquiry	1.1K → 1.0K(-38)	99.8% → 99.6%(↓ -0.2pp)	7.6%

Return Code

Name	Transaction Volume	Response Rate	Impact
No Response	412 → 687(+275)	0.0% → 0.0%	100.0%

Server IP

Name	Transaction Volume	Response Rate	Impact
10.30.0.1	12.5K → 12.0K(-433)	99.7% → 99.5%(↓ -0.2pp)	100.0%

Client IP

Name	Transaction Volume	Response Rate	Impact
192.168.10.1	12.5K → 12.0K(-433)	99.7% → 99.5%(↓ -0.2pp)	100.0%

Network Correlation ⤢

ANOMALIES DETECTED

Availability DEGRADED

TCP Setup Success ↓ 54.37% (-25.63pp)

TCP RST ↑ 0.00

Performance DEGRADED

Retransmission Rate ↑ 2.24% (+0.96pp)

Duplicate ACK ↑ 18.42 (+6)

Packet Loss ↑ 287.00 (+52)

Traffic NORMAL

Throughput ↑ 152.63 Kbps (+12.4K)

New Connections ↑ 1847.00 (+312)
